Instruction Manual

6

System requirements

Bus Interface

PCI Express 2.0

(x1 slot connector)

SATA revision 3.0

Form Factor Full/Low Prole

Chipset ID Marvell 9128

Connectors

1 x 7-pin SATA

1 x 7-pin eSATA

LEDs 2 x Activity (via header)

Maximum Data Transfer Rate SATA: 6Gbps

Supported RAID Modes JBOD (single), 0, 1

Port Multiplier Support Yes

Operating Temperature 5°C ~ 50°C (41°F ~ 122°F)

Storage Temperature -25°C ~ 70°C (-13°F ~ 158°F)

Humidity 15 ~ 90% RH

Compatible Operating Systems

Windows XP(32/64bit)/Server

2003(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/

Server 2008 R2, Linux
