4 Port USB A Female Slot Plate Adapter

StarTech ID: USBPLATE4

The USBPLATE4 4 port USB 2.0 slot plate adapter converts the USB pins on your motherboard into four USB-A

female ports, enabling you to add USB connections to the back of your PC.

Backed by Lifetime Warranty, the USBPLATE4 is designed and constructed for maximum durability, to ensure

dependable performance.

Please Note: Check your motherboard’s manual for the USB pinout diagram. The USBPLATE wiring scheme is:

Red=Power, Green=Signal, White=Signal, Black=Ground

Applications

Mount four USB-A female ports to the back of your PC by connecting them to 2x 4 or 5 pin IDC

motherboard connections

Features

4x USB-A female ports

2x IDC 10-pin Female connectors

Supports 4 or 5 pin motherboard connections

Separate cables supports 2 rows of 4/5

www.startech.com

1 800 265 1844

1 2

4 Port USB A Female Slot Plate AdapterStarTech ID: USBPLATE4The USBPLATE4 4 port USB 2.0 slot plate adapter converts the USB pins on your motherboard

Seite 2

Technical SpecificationsWarranty LifetimeConnector A 2 - IDC (10 pin; Motherboard Header) FemaleConnector B 4 - USB A (4 pin) FemaleType and Rate USB
