2 Port SATA to eSATA Slot Plate Bracket

StarTech ID: ESATAPLATE2

StarTech.com's eSATA SATA adapter plate adds external data support to any existing Serial ATA controller,

adding two eSATA ports for connection to external SATA devices.

The adapter plate can be mounted to the rear panel of the computer case, providing straightforward eSATA to

SATA connections and allowing users to connect their eSATA device (hard drive enclosure, etc.) to the provided

eSATA port which is an extension of the motherboard SATA data connector.

Designed to take advantage of the increased data integrity provided by external hard drives or RAID devices

that support eSATA connections, the eSATA SATA adapter supports data transfer rates of up to 6Gbps and is

backed by StarTech.com's Lifetime Warranty.

Features

Compliant with Serial ATA III Specifications

Technical Specifications

Warranty Lifetime

Connector Type(s) 2 - eSATA (7 pin; Data) Plug

Connector Type(s) 2 - SATA (7 pin; Data) Receptacle

Product Length 1 ft [0.3 m]

Shipping (Package) Weight 0.1 lb [0.1 kg]

Included in Package 1 - 2 Port SATA to eSATA Slot Plate Bracket

Certifications, Reports and Compatibility

www.startech.com

1 800 265 1844

Features 1
Technical Specifications 1
