10 ft Coax High Resolution 90° Upward Angled VGA Monitor Cable - HD15 M/M

StarTech ID: MXT101MMHU10

This 10ft upward-angle VGA cable is designed to support the highest resolutions and highest video quality

possible through VGA while fitting perfectly in tight connection spaces. The cable features one standard VGA

connector (HD15) and one VGA connector (HD15) that is situated on an upward angle relative to the shaft of the

cable, requiring only 32.4mm of space at the connection point.

Suited for high resolution VGA applications (1280x1024 and above), this high quality coaxial VGA cable

eliminates picture "ghosting" and fuzzy images inherent to non-coaxial cables, and provides superior EMI

interference protection using ferrite cores near the connector ends.

Applications

Connecting Multimedia Servers

POS Displays

Features

90° Upward Angled connector with a 32.4mm depth

Ferrite core eliminates EMI interference

Ideal for high resolution monitors (1280x1024 and above)

Impedance matched at 75 Ohms for full brightness and vibrant picture color

Molded connector ends with strain relief

Triple-coaxial + twisted-pair wire for crystal clear display

www.startech.com

1 800 265 1844

1 2

Applications 1
Features 1

Inhaltsverzeichnis

Seite 1 - Features

10 ft Coax High Resolution 90° Upward Angled VGA Monitor Cable - HD15 M/MStarTech ID: MXT101MMHU10This 10ft upward-angle VGA cable is designed

Seite 2

Technical SpecificationsWarranty LifetimeCable Jacket Type PVC - Polyvinyl ChlorideNumber of Ferrites 1Connector A 1 - VGA (15 pin; High Density D-Sub
