StarTech.com MXT105HQ Datenblatt PDF herunterladen

15 ft Coax VGA Monitor Extension Cable - HD15 M/F

StarTech ID: MXT105HQ

This 15ft High Resolution VGA Monitor Extension Cable is designed to provide the highest VGA video quality

possible. Ideally suited for high resolution VGA applications (1024x768 and above), this high quality coaxial

VGA cable eliminates picture "ghosting" and fuzzy images inherent to non-coaxial cables and provides superior

EMI interference protection by using ferrite cores near the connector ends.

A reliable solution for a wide range of applications, including connecting StarView KVM Switches, this high

resolution VGA (SVGA) extension cable features one hddb15 male connector and one hddb15 female

connector, offering a convenient way to extend a VGA or SVGA connection by up to 15ft, while maintaining

superb image quality.

Applications

Extends VGA/SVGA monitor cable

Connects PC's VGA port to a StarView

Features

Ideal for high resolution monitors (1024x768 and above)

Triple-coaxial + twisted-pair wire for crystal clear display

Impedence matched at 75 Ohms for full brightness and vibrant picture color

Ferrite core eliminates EMI interference

Molded connector ends with strain relief

www.startech.com

1 800 265 1844

1 2

Applications 1
Features 1

Inhaltsverzeichnis

Seite 1 - Features

15 ft Coax VGA Monitor Extension Cable - HD15 M/FStarTech ID: MXT105HQThis 15ft High Resolution VGA Monitor Extension Cable is designed to provide the

Seite 2

Technical SpecificationsWarranty LifetimeConnector Plating NickelConnector A 1 - VGA (15 pin; High Density D-Sub) MaleConnector B 1 - VGA (15 pin; Hig
